Frame

0289

Untraced

“653 TUBING” is written and underlined across the head of the sheet. No year appears on the sheet or its four attachment pages, so the order carries only its day, “Jan 31”; the delivery and deposit boxes are empty on the pro-forma. With the sheet is a four-page letter to Sid dated the same Jan 31, enclosing a £100 deposit cheque post-dated Feb 6th (“my pay day”), the balance to follow in cash. The letter confirms the 21" frame “as agreed last Saturday”, reasons out a 21½" top tube against the writer's Carlton (with a sketch), asks for gold outer cables and gold bar tape (“not white, not yellow”), toe straps too, queries the cable-guide runs, leaves the saddle to be decided between plastic and a Brooks Pro, and confirms 653 tubing, 73° parallel, 21", brazed-on fittings, mudguard clearance, 700c; a final page headed “gear ratios” asks for 50x40 rather than 52x42 — “I prefer to pedal rather than push”. It is signed Malcolm.

Ordered: Jan 31
Tubing: 653
Frame: 21"
Top tube: 21½"
Angles: 73° / 73°
Forks: Cinelli crown
Ends: Columbus (eyes)
Seatstays: Duo-Taper Fastback
B/bracket: Height 10⅝"
Headset: 105 STD
Wheels: Clearance for H.P.'s (sprints struck out), with mudguard clearance (no struck out)
Brazed on: Gear lever bosses “Yes”, h'bar control eyes, gear lever clip pip, “Tunnels” written above the 5/10-speed brazings line (the 5 struck out), lamp boss, brake eyes “LHS 45°”, pump pegs, centre-pull brake bridge, TA bottle cage bosses “Yes”, A.K. seat lug ticked
Finish: Ruby Flam, lugs lined gold
Customer: Malc Greaves, North Wingfield, Chesterfield

Own this sheet

£110

A high-resolution print of the sheet, not the original. Giclée on enhanced matte art paper, mounted in snow white, glazed, in a solid wood frame. Free UK postage. £15 goes to Lincs & Notts Air Ambulance.

See it framed — £110

Print only £35

See it before you buy · Pay by card or PayPal · Free UK postage

A print of the 0289 sheet, framed — to scale above a two-metre sofa

Own it? Remember it?

Nobody has come forward for 0289 yet. If it is in your shed, or you remember it being built, ridden or sold, send a photograph and whatever you know.

Send photographs and what you know

Read before anything appears · Nothing published without it

Filed with it

4 more pages in the folder

Kept in the folder with the worksheet and scanned with it: the build written out and ticked off as it was fitted, a letter, a sketch, the second side of the sheet. The worksheet is the record; these are what was going on around it. Tap one to read it full size.
