Frame

0397

Untraced

A hub-geared light tourer with two pages of working notes attached. The first is headed “SUPERBE 531 C” and sets the intent — a light, low-maintenance touring bike with hub gears and brakes, “quite responsive”, higher-than-normal head tube, rising top tube, relaxed angles “but not too much”, clearance for wide tyres, rear drop-outs to have two sets of eyes, a dynamo “as on Batavus (small brazing - AXA HR dynamo)” and Carradice racks front and rear; a note records the Campag Veloce headset “has been v. good”. The second page dimensions the Nexus brazings: a slotted tab for the brake bracing arm on the nearside chainstay, cable guides on the down tube and chainstays with distances from the BB shell and fork crown, “Remove hanger”, and “AXA/HR Dyno bracket to be brazed on forks, nearside”. A struck-out line on the order sheet reads “See ‘Streetwise’ for details of chaincover”. Delivery promised A.S.A.P.; a telephone number sits beside the frame number.

Ordered: 5.3.97
Tubing: 531 Comp.
Frame: 22"
Top tube: 20"/21" (Sloping)
Angles: 72° / 73°
Forks: 14¾ x 2", std crown
Ends: Columbus with eyes (double on rear)
Chainstays: 16¾"
B/bracket: 10⅝"
Headset: Veloce/Mirage
Wheels: 700C Mavic 221, H.P.s (sprints struck out), with mudguard clearance
Equipment: Shimano sealed B.B. UN71; Nexus 7 hub roller (“coaster” struck out); lever Rapidfire ST 7520; pannier bosses rear 4 point; Carradice front & rear racks; BL 1M40 SB 7540?
Brazed on: Wrap-over seat lug (the printed A.K. struck out), brake eyes “see list”, TA bottle cage bosses “see sheet”
Finish: Pearlescent (60) Racing Green, lugs lined gold, old style transfers
Customer: Anthony Johnson, West Bridgford
