Frame

81126

UntracedLedger: sold

Order received 25 August 1981, delivery promised about six weeks. Enamelled 22-9-81.

Ordered: 25-8-81
Tubing: 531 DB
Frame: 23½" racing
Top tube: 22½"
Angles: 74° / 74°
Forks: 1¼" × 14¼"
Fork type: S/L forks
Ends: Sup. Record
Chainstays: Short, with Campag front changer
Seatstays: 5/8
B/bracket: 10 5/8
Headset: Standard
Brazed on: 10 speed tunnels, pip eye, TA bosses, guides top of top tube. Bridges top 13 3/4
Finish: Gold poly, red head, 8" red seat tube band, lug line, Superbe transfers
Customer: Chris Denny
Signed: S. Standard

Own this sheet

£85

Giclée on cotton rag, oak or black ash, mounted and glazed. Free UK postage. £15 goes to Lincs & Notts Air Ambulance.

Pay by card or PayPal · Free UK postage

Is this your frame? Tell us where it ended up.

As written

The page, line by line

Transcribed as it appears, including the abbreviations. Underlining and the red pencil struck across the job are on the sheet itself.

531 DB    S/L FORKS
ORDER REC'D. 25-8-81
FRAME No. 81126    DEL. PM'S'D. 6 WKS APPROX.
23½ RACING.
ANGLES.    74° 74°
T.T.    22½"
ENDS    SUP. RECORD.
C/STAYS    SHORT WITH CAMPAG FRONT CHANGER
S/STAYS.    5/8.
FORKS.    1¼ × 14¼
BKT.    10 5/8
H/Set    STD
BRAKES    Galli (as in window)
Bridges. Top 13 3/4  BTM.
BRAZED ON  10 SPEED TUNNELS PIP EYE,
T.A. BOSSES, GUIDES TOP OF T/T.
FINISH    GOLD POLY.
Red Head  8" Red ST Band.
Lug line  Superbe trans.
SOLD
Customer  Chris Denny
ACS 22-9-81
S. Standard
