Frame

841019

Untraced

No date appears anywhere on the sheet, so no year is recorded, and no finish is recorded at all. The size box reads “27½"” as written — unusually large, and possibly a slip given the 23¼" top tube. The type-of-brakes line is read as “4700 mm” but the hand is fast and the figure may be something else, perhaps a caliper-drop measurement.

Frame: 27½"
Top tube: 23¼"
Angles: 73° / 73°
Forks: 1⅞ rake
Ends: Campag Record
Chainstays: 17¼
B/bracket: 10⅞" height
Headset: STD
Wheels: 27" with guards (“27's & GDS” written at the head; sprints struck out), with mudguard clearance
Brazed on: Gear lever clip pip (ticked), Campag tunnel for 10-speed (the printed 5 struck out), lamp boss (“Yes”), brake eyes 45° under the top tube, L.H.S., one pump peg (“pump to supply”), TA bottle cage bosses “Yes, high up”
Customer: John Clark, Forest Fields

Own this sheet

£110

A high-resolution print of the sheet, not the original. Giclée on enhanced matte art paper, mounted in snow white, glazed, in a solid wood frame. Free UK postage. £15 goes to Lincs & Notts Air Ambulance.

See it framed — £110

Print only £35

See it before you buy · Pay by card or PayPal · Free UK postage

A print of the 841019 sheet, framed — to scale above a two-metre sofa

Own it? Remember it?

Nobody has come forward for 841019 yet. If it is in your shed, or you remember it being built, ridden or sold, send a photograph and whatever you know.

Send photographs and what you know

Read before anything appears · Nothing published without it
